NKX60 INA Complex Bearings

NKX60 INA Complex Bearings

Name	NKX60	NKX60	NKX60-Z
Brand	INA	NTN	INA
Size (mm)	60x72x40(mm)		60x72x40(mm)
Fw	60 mm 2.3622 in		60 mm 2.3622 in
D	72 mm 2.8346 in	72 mm 2.8346 in	72 mm 2.8346 in
C - 40 mm / Tolerance: -0,25	40 mm / Tolerance: 0,25 1.5748 in		40 mm / Tolerance: 0,25 1.5748 in
C1 - 17 mm / Tolerance: -0,2	17 mm / Tolerance: 0,2 0.6693 in		17 mm / Tolerance: 0,2 0.6693 in
C2	12 mm 0.4724 in		12 mm 0.4724 in
Bore Diameter (mm)	60(mm)	60(mm)	60(mm)
D1 max	85,2 mm 3.3543 in
da	80,5 mm 3.1693 in		80,5 mm 3.1693 in
Outer Diameter (mm)	72(mm)	85(mm)	72(mm)
dw	60 mm / Tolerance: E8 2.3622 in		60 mm / Tolerance: E8 2.3622 in
ra max	1 mm 0.0394 in		1 mm 0.0394 in
Width (mm)	40(mm)		40(mm)
rmin	1 mm 0.0394 in		1 mm 0.0394 in
	IR50X60X25 / Suitable inner ring		IR50X60X25 / Suitable inner ring
m	360 g / Weight		380 g / Weight
Cr	47500 N / Dynamic load rating (radial)		47500 N / Dynamic load rating (radial)
C0r	90000 N / Static load rating (radial)		90000 N / Static load rating (radial)
Ca	41500 N / Dynamic load rating (axial)		41500 N / Dynamic load rating (axial)
C0a	113000 N / Static load rating (axial)		113000 N / Static load rating (axial)
Cur	15400 N / Fatigue limit load, radial		15400 N / Fatigue limit load, radial
Cua	5400 N / Fatigue limit load, axial		5400 N / Fatigue limit load, axial
nG	2800 1/min / Limiting speed		2800 1/min / Limiting speed
